Description
SAPT 4Pack 3.2V 30C LiFePo4 8Ah Battery.
SAPT 8Ah Cells
| Item | Specification | |
| 1 | Nominal Capacity | 8Ah (Min capacity:8Ah, Discharge at 1I1 A) |
| 2 | Charging End Voltage | 3.65V |
| 3 | Average working Voltage | 3.2V (Discharge at 1I1 A ) |
| 4 | AC-impedance | ≤ 1.3mΩ |
| 5 | Standard Charge Method | Constant Current and Constant Voltage (CC/CV) |
| 6 | Current | 1I1 A |
| 7 | Voltage | 3.25V |
| 8 | End Current | 425mA |
| 9 | Maximum Charge Current | 10 I1（Continuous） 15I1(30s) 20I1(10s) |
| 10 | Standard Discharge | Constant Current (CC) |
| 11 | Current | 1I1 A |
| 12 | End Voltage | 2.5V |
| 13 | Maximum Discharge Current | 20I1（Continuous） 30I1 (30s) |
| 14 | Cycle Life | Capacity≥80% Nominal Capacity @2000th cycles |
| 15 | Weight of Bare Cell | 320±10g for one cell |
| 16 | Dimensions | 3.2 * 0.6 * 5 (In) for one cell |
| 17 | Max Operating Temperature Range | |
| Charge | -10℃ ~ 45℃ | |
| Discharge | -20℃ ~ 60℃ | |
| 18 | Optimal Operating Temperature Range | |
| Charge | 15℃ ~ 35℃ | |
| Discharge | 15℃ ~ 35℃ | |
| 19 | Storage Temperature | |
| 1 month | -40℃~ 45℃ | |
| 6 months | -20℃ ~ 35°C | |
| 20 | Data Sheet | SAPT Cells specifications |
| Cells should storage in 30% SOC or the voltage range is 3.275V～3.304V | ||
